low noise / high speed / wide-range application / great precision
WHAT IS A SEWING MACHINE?
Shoes sewing machine is applied for shoes/bags/caps and other applicalions. Shoes sewing machine can sew and punch at a time,improve production efficiency.Our machines can do punching and sewing in one time .Perfect hole shapes and stitch lines.
TYPES OF SEWING MACHINE

HOW TO CHOOSE YOUR SEWING MACHINE?

Sewing Area

300*200mm

Maximum Sewing Speed

2800rpm

Sewing Trace

Single Needle Flat Seam

Feeding

Intermittent Feeding(Pulse Motor Drive)

Stitches Length

0.05-12.7mm

Maximum Stitches

30000 Stitches Per Pattern

Stored Stitches

Built-in Memory Can Store 500000 Stitches

Foot Driving Method

S-pulse Motor Drive

Pressing Foot Height

25-30mm

Height Of Big Presser Foot

Maximum 30mm

Air Pressure

0.5MPa 1.8L/min

Supply Voltage

AC 220V

Media

With Sound Alarm Device

Intermittent Pressure Lift

22mm

Stored Programs

1~999 Patterns

Machine Size

1200*1200*1240mm

Weight

180 KG

Sewing Area

350*250mm

Maximum Sewing Speed

2500rpm
Sewing Trace Double Needle Flat Seam
Feeding Intermittent feeding (Pulse Motor Drive)
Stitches Length 0.05-12.7mm
Maximum Stitches 30000 Stitches Per Pattern
Stored Stitches Built-in Memory Can Store 500000 Stitches
Foot Driving Method S-pulse Motor Drive
Pressing Foot Height 25-30mm
Height Of Big Presser Foot Maximum 30mm
Air Pressure 0.5MPa 1.8L/min
Supply Voltage AC 220V
Media With Sound Alarm Device
Intermittent Pressure Lift 22mm
Stored Programs 1~999 Patterns
Machine Size 1200*1200*1240mm
Weight 180KG

Sewing Area

350*250mm

Maximum Sewing Speed

2700rpm
Rotary Shuttle Style Swing Shuttle (Bobbin Diameter 24mm Thickness 14mm)

Feeding

Intermittent Feeding(Pulse Motor Drive)

Stitches Length

0.05-12.7mm

Maximum Stitches

30000 Stitches Per Pattern

Pressing Foot Height 25-30mm
Intermittent Pressure Lift 22mm
Motor 750W AC Direct Drive Servo Motor
Air Pressure 0.5 Mpa 1.8 L/min
Power Supply Single Phase 110-120v 200-240v
Machine Size

2210*1360*1350mm

Weight 400KG

Sewing Area

450*300mm

Maximum Sewing Speed

2500rpm
Height Of Pressing Foot Lift 25mm
Presser Foot Lift Mode Automatic
Seam Length 43.2mm
Refueling Automatic
Automatic Trimming Yes
Emergency Stop Yes
Motor Servo Motor
Shuttle Style Full Rotation 3 x Shuttle
Air Pressure 0.5MPa 1.8L/min
Supply Voltage AC 220V Single Phase
Use Machine Needle DP*17
Machine Size 2150*1460*1630mm
Weight 1200KG

Sewing Area

120*80mm

Maximum Sewing Speed

2700rpm
Sewing Trace Single Needle Flat Seam
Feeding Intermittent feeding (Pulse Motor Drive Mode)
Intermittent Presser Foot Lift 17mm
Hook Shuttle Hook
Presser Foot Lifting Mode Pulse Motor Drive Mode
Motor AC Servo Motor 750W Direct Drive
Air Pressure 0.5MPa 1.8L/min
Power Supply Single-phase 220V
Machine Size 1320*1000*1280mm
Weight 210KG

Sewing Area

350*250mm

Maximum Sewing Speed

2700rpm
Sewing Trace Single Needle Flat Seam
Perforation Range 0.8-6mm
Rising Amount Of Intermittent Foot Presser 22mm
Stroke By Intermittent Presser Foot 0 or 2 - 10m.Factory Settings 3mm
Motor AC Servomotor 750W
Air Pressure 0.5 Mpa 1.8 L/min
Supply Voltage AC 220V Single Phase
Machine Size 1300*1250*1560mm
Weight 250KG
ADVANTAGE OF SEWING MACHINE
advantage of sewing machine

  To enhance corporate image.
To improve the production environment and reduce the intensity of work.
To improve the traditional production management.
Programmable Pattern Machine makes production more stable, accurate production data. Production and order arrangements with accuracy, reduce labor usage, sewing quality and stability, reduce the quality management friction.
To improve production efficiency
Sewing handbags, the efficiency of one pattern machine is equal to the traditional day of production sewing machine operator 7 staffs efficiency.
To reduce costs
Pattern machine as full computerized system control, stable quality, scrap rate is zero.
To improve products quality
greatly, improve product quality and competitiveness, thereby increasing corporate profits and brand reputation.
Programmable Electronic Pattern Sewing Machine compared with traditional Sewing Machine:
